CCD bracket reversing camera with 4 pin connectors PAL
CCD bracket reversing camera with 4 pin connectors PAL

CCD bracket reversing camera with 4 pin connectors PAL

(Inc. 20% VAT)
(£56.67 Exc. VAT)
In stock
350 g
Introduction to product

This design of reversing camera has been around for many years. They are the most popular design for larger vehicles such as lorries and farm vehicles. Our supplier for these cameras use top quality moulds that use rubber seals rather than sealant you find in cheaper cameras. They are tested to IP69 and in our experience very rarely have issues with water getting in. They use a 1/3" Sony 700 TVL CCD sensor which gives an excellent picture day and night. We use a stainless steel bracket to avoid corrosion of the bracket which is common with mild steel ones. They use our 4 pin connector that locks and is waterproof.

The one photograph shows the field of view obtained by this camera. At a typical mounting height it will cover the full width and more of the vehicle. Manufacturers often give inaccurate specifications for camera angle which is why we show images in real life situations.

We occassionally have clearance versions at a discount. THEY MAY BE OF A DIFFERENT SPECIFICATION. They will be on clearance usually for paint marks, new customer returns (change of mind) or old stock. Also they may be of a lower specification like a mild steel bracket or Sharp 1/3" CCD sensor at 420 or 480 TVL. You will find these in our clearance section if any are available.

Specification of camera
  • 1/3 700TVL SONY CCD
  • Video System:- PAL
  • Pixels:- PAL:752(H)*582(V)
  • Horizontal Resolution:-700 TVL
  • Min Illumination:- 0.001Lux (0 Lux IR on)
  • SNR:- ≥50dB
  • Electronic Shutter:- 1-1/10000(S)
  • Video Output:- 1.0V±0.5Vp-p 75Ω
  • View Angle:- 120°  (Unless stated otherwise in information tab)
  • Working Voltage:- DC9V-12V±0.5V
  • Consumption:- 70mA±10%
  • Waterproof Rate:- IP68
Bar Code
Van, HGV, Tractor
12 volt
Connector type
4 pin aviation
700 TVL
Special features
18 IR LEDs for night vision
Type of sensor
Sensor manufacturer
Sensor size
1/3" sensor
Camera angle
120 degrees
