Heavy duty 7 inch AHD dash mount monitor and 2 bracket reversing cameras

£252.00
(Inc. 20% VAT)
(£210.00 Exc. VAT)
+
Weight
2.50 kg
Introduction to product

Heavy duty 7 inch AHD dash mount monitor and 2 AHD bracket reversing cameras. This kit is ideal for horseboxes where you have one camera monitoring the horses and another mounted at the rear for reversing. It has the capability to take 3 cameras so the option is there to add a third camera.

With AHD systems we do not advise using them with a trailer link.

Specification of Camera

I

  • Image sensor and chips: FH8550M+C2398
  • Resolution: 1920*1080P (2 million pixels)
  • Night Vision: 850 / IR-CUT night vision
  • Wide Dynamic: Support (mobile frame rate 100DB)
  • SNR: >52DB (AGC OFF)
  • System: PAL
  • Image: Mirror image
  • Waterproof Level: IP68
  • Shockproof Level: 4G
  • Connectors: 4 Pin aviation
  • Power Supply: 12V (our monitors supply 12V to the camera regardless of their input voltage)
  • Power Consumption: Approx 1.8W per camera
  • Video Output: 1080P
  • Working Temperature: -20°C to +70°C
  • Storage Temperature: -30°C to 85°C
  • Stainless Steel Bracket (painted)
Specification of monitor
  • 7” Diagonally Measured Colour IPS screen
  • Power supply: 12V/24V
  • Power Consumption: 7.5W Max
  • Digital Screen Resolution: 1024 x3(RGB)x600
  • 3 Hybrid Inputs
  • PAL/NTSC/AUTO
  • Full function Remote Control
Model
HD705AHDdual
