Brake light reversing camera for New Mercerdes Vito 2016+
Brake light reversing camera for New Mercerdes Vito 2016+

Brake light reversing camera for New Mercerdes Vito 2016+

£90.00
(Inc. 20% VAT)
(£75.00 Exc. VAT)
4 in stock
+
Weight
400 g
Introduction to product

This reversing camera is for the Mercedes Vito with tail lift from 2016. It replaces the existing brake light and means no holes need to be drilled to fit a reversing camera. It uses a PC4089 700 TVL CMOS sensor, giving a colour high resolution image during the day. At night it gives a useable image with the assistance of street lighting and the vehicle lights. The camera has a quoted 170 degree viewing angle, but we feel it is much closer to 150 degrees. It will give the complete width of the van plus a little extra either side. The camera uses a high quality glass lens for long term reliability (plastic ones tend to  discolour).

The camera is supplied with a short fly lead to a 4 pin aviation connector. There is the option to buy a 4 pin extension cable using the drop down menu. If being used with a after market head unit then there is also an option buy buy a 4 pin to RCA connector adaptor.

Specification of camera

Specification

  • Image device:- PC4089 CMOS sensor
  • Resolution: 700 TVL
  • Mirror image
  • IP rating: Ip68
  • Camera angle: 170 degrees diagonal
  • HD all glass composite lens
  • 10G vibration rating





Model
CAM440
Bar Code
5060342252692
Voltage
12 volt
TVL
700 TVL
Type of sensor
CMOS
Sensor size
1/3" sensor
Camera angle
150 degrees
